7K Dump

Eagle TrailersDump

7K Dump

7K Dump

Models & Sizes

ED508TA2
5 ' x 8 ' Tandem Axle Heavy Duty Dump
Curb Wt
2110 lb
GVWR
7000 lb
ED608TA2
6 ' x 8 ' Tandem Axle Heavy Duty Dump w/ 43" Sides and 15K Lift
Curb Wt
2450 lb
GVWR
7000 lb
ED510TA2
5 ' x 10 ' Tandem Axle Heavy Duty Dump
Curb Wt
2200 lb
GVWR
7000 lb
ED610TA2
6 ' x 10 ' Tandem Axle Heavy Duty Dump
Curb Wt
2270 lb
GVWR
7000 lb
ED612TA2
6 ' x 12 ' Tandem Axle Heavy Duty Dump
Curb Wt
2440 lb
GVWR
7000 lb
ED710TA2
7 ' x 10 ' Tandem Axle Heavy Duty Dump
Curb Wt
2400 lb
GVWR
7000 lb
ED712TA2
7 ' x 12 ' Tandem Axle Heavy Duty Dump
Curb Wt
2580 lb
GVWR
7000 lb

Available Units

Standard Features

25/16 " Coupler w / 2K Top Wind Jack
Brakes Both Axles
10 gauge ( - ) Floor and Side Walls
Tread Plate Fenders
Stake Pockets
Tube Tongue ( Longer than competition )
Front and Rear Diamond Plate Fender Steps
2 " Flat Bar Heavy Duty Tie Rail
Trickle Charge Line From Tow Vehicle
HD Deep Cycle Battery
15 " Wheels & Tires ( Radial )
Direct Push 5 " Bore Hydraulic Cylinder
Sealed Beam LED Lights
Electric / Hydraulic Pump with Reservoir and Gravity
Override
PPG Primer and Paint
Tarp Bar
Lockable Tongue Box

Popular Options

Stored Heavy Duty Ramps w/ 4 D-Rings

Specifications

GAWR: 7000
Coupler Height: 18"
Deck Height: 28"
Main Frame: 4" Channel 3" Channel Cross Members and Reinforced Frame for Direct Push 5" Bore Hydraulic Cylinder
Axle: 2 ( 3,500 # ) Posi - Lube Axle with Brakes
Floor: 10 Gauge (-) Steel Floor
Sides: 10 Gauge (-)
Coupler: 2 5/16 " Coupler
Dump Box Frame: 2 " x 4 " Rectangle Tube ( .120 " ) 1 ½ " x 1½ " Heavy Wall Tubing 16 " on Center Barn Doors 10 gauge ( - ) sides ( Note : with ramps 2 " x 5 " dump box frame )

Available Colors

Primary Colors

Black ALK-FP901

Eagle Majestic Grey

Optional Colors (Additional Cost)

White ALK-FP951

Bright Yellow ALK-FP801

Cat Yellow ALK-FP827

Ford Blue ALK-FP101

Ice Gray ALK-FP301

John Deer Green ALK-FP401
