Models & Sizes
FU406SA
4’ x 6’ Single Axle Falcon Utility
- Curb Wt
- 610 lb
- GVWR
- 2990 lb
FU408SA
4’ x 8’ Single Axle Falcon Utility
- Curb Wt
- 675 lb
- GVWR
- 2990 lb
FU508SA
5’ x 8’ Single Axle Falcon Utility
- Curb Wt
- 700 lb
- GVWR
- 2990 lb
FU510SA
5’ x 10’ Single Axle Falcon Utility
- Curb Wt
- 750 lb
- GVWR
- 2990 lb
FU610SA
6’ x 10’ Single Axle Falcon Utility
- Curb Wt
- 825 lb
- GVWR
- 2990 lb
FU6610SA
6’6” x 10’ Single Axle Falcon Utility
- Curb Wt
- 850 lb
- GVWR
- 2990 lb
FU612SA
6’ x 12’ Single Axle Falcon Utility
- Curb Wt
- 945 lb
- GVWR
- 2990 lb
FU6612SA
6’6” x 12’ Single Axle Falcon Utility
- Curb Wt
- 1035 lb
- GVWR
- 2990 lb
FU614SA
6’ x 14’ Single Axle Falcon Utility
- Curb Wt
- 1065 lb
- GVWR
- 2990 lb
FU714SA
7’ x 14’ Single Axle Falcon Utility
- Curb Wt
- 1095 lb
- GVWR
- 2990 lb
Available Units
Standard Features
- 2” Coupler with 2K Top Wind Tongue Jack
- 15” Wheels & Tires (Radial)
- Sealed Beam LED Lights
- PPG Primer and Paint
- 2” x 6” #2 or Better Fir Decking
- Tube Tongue (longer than competition)
- Front Fender Step with Light
- J-Hooks (4 per side, 1 in front)
- 24” Solid Metal Sides
- Square Tube Top Tie Rail 30” Total Height
- 4’ Ramp
Popular Options
- Tongue Box Steel or Aluminum Diamond Plate
- Pressure Treated Decking
- Swing up Tongue Jack with Wheel
- Nylon Reinforced Vinyl Tarp Complete with Aluminum Cross Supports and Nylon Stretch Tie Rope
- Solid Metal Rear Swing Gate
- Spare Tire and/or Mount
- Rear Barn Doors
- No Gap Stake Pocket Top
- Four Small D-Rings
Specifications
- GAWR
- 3500
- Coupler Height
- 16"
- Deck Height
- 18"
- Frame
- 2" x 2" Angle
- Axle
- 3,500# Posi-Lube Axles (Idler)
- Cross Members
- 2" x 2" Angle
- Decking
- 2 x 6 #2 or Better Fir Decking
- Sides
- 24" 16 Gauge Smooth Steel 30" to Top of Rail
- Coupler
- 2" A-Frame
- Electric Plug
- Flat 4-Way Molded Water Tight Plug
- Fenders
- 9" x 32"
- Finish
- Steel is cleaned (wiped down) to ensure quality protective finish
- Jack
- 2K Top Wind Tongue Jack
- Lights
- Sealed Beam LED Lights
- Paint
- PPG Primer and Paint
- Ramps
- 48" Ramp 1 1/2" x 1 1/2" Square Tube
- Safety Chain
- 30" x 1/4" 5.2K Capacity
- Suspension
- Multi-Leaf Spring
- Tires
- ST 205/75 D15 Load Range C
- Tongue
- 2" x 3" Rectangular Tube
- Top Rail
- 1 1/2" x 1 1/2" Square Tube
- Uprights
- 2" x 1" Rectangle Tube
- Wheels
- 15 x 5 5-4.5 Mod (Silver)
Available Colors
Primary Colors
Black ALK-FP901
Eagle Majestic Grey
Optional Colors (Additional Cost)
White ALK-FP951
Bright Yellow ALK-FP801
Cat Yellow ALK-FP827
Ford Blue ALK-FP101
Ice Gray ALK-FP301
John Deer Green ALK-FP401
Kubota Orange ALK-FP601
Case IH Red ALK-FP701
