Models & Sizes
EUCLP712TA3
7’ x 12’ Tandem Axle Ultra with Landscape Package
- Curb Wt
- 2310 lb
- GVWR
- 10000 lb
EUCLP714TA3
7’ x 14’ Tandem Axle Ultra with Landscape Package
- Curb Wt
- 2410 lb
- GVWR
- 10000 lb
EUCLP716TA3
7’ x 16’ Tandem Axle Ultra with Landscape Package
- Curb Wt
- 2540 lb
- GVWR
- 10000 lb
EUCLP718TA3
7’ x 18’ Tandem Axle Ultra with Landscape Package
- Curb Wt
- 2615 lb
- GVWR
- 10000 lb
Available Units
Standard Features
- 2’ x 2’ Front Opening Lockable Tool Box with 6” Tray
- 6 Shovel and Rake Holders (Side Mount)
- 2 Place Weed Eater Rack
- Ladder Rack
- 2 5/16” Adjustable Coupler with 7K Drop Leg Jack
- 15” Wheels & Tires (Radial)
- Sealed Beam LED Lights
- PPG Primer and Paint
- 4’ Expanded Metal Ramp
- 2” x 6” #2 or Better Fir Decking
- Tube Tongue (longer than competition)
- Full Length Expanded Metal Steps
- Tongue Tray
- Ribbed Metal Sides
Popular Options
- Pressure Treated Decking
- Spare Tire and/or Mount
- 3 Place Weed Eater Rack
- 4’ Side Ramp Gate
Specifications
- GAWR
- 10400
- Coupler Height
- Adjustable
- Deck Height
- 19"
- Frame
- 5" Channel
- Axle
- (2) 5,200# Posi-Lube Axle w/ Brakes
- Cross Members
- 3" Channel
- Decking
- 2 x 6 #2 or Better Fir Decking
- Sides
- 24" 16 Gauge Sidewall 30" to Top of Rail
- Coupler
- Adjustable 2 5/16" Coupler
- Electric Plug
- 7-Way RV Molded Water Tight Plug
- Fenders
- 9" x 72" Heavy Duty Diamond Plate
- Finish
- Steel is cleaned (wiped down) to ensure quality protective finish
- Jack
- 7K Drop Leg Jack
- Lights
- Sealed Beam LED Lights
- Paint
- PPG Primer and Paint
- Ramps
- 4' Expanded Metal Ramp
- Safety Chain
- 35" x .3125" 16.2K Capacity
- Suspension
- Multi-Leaf Spring
- Tires
- ST 225/75 R15 Load Range D
- Tongue
- 2" x 4" Tube
- Top Rail
- 2" x 1" Tube
- Uprights
- 2" x 1" Tube
- Wheels
- 15 x 6 6-5.5 Mod (Silver)
Available Colors
Primary Colors
Black ALK-FP901
Eagle Majestic Grey
Optional Colors (Additional Cost)
White ALK-FP951
Bright Yellow ALK-FP801
Cat Yellow ALK-FP827
Ford Blue ALK-FP101
Ice Gray ALK-FP301
John Deer Green ALK-FP401
Kubota Orange ALK-FP601
Case IH Red ALK-FP701
