Models & Sizes
E4FB710TA2
7'x10 ' Tandem Axle 4 " Channel Flatbed
- Curb Wt
- 1310 lb
- GVWR
- 7000 lb
E4FB712TA2
7 ' x 12 ' Tandem Axle 4 " Channel Flatbed
- Curb Wt
- 1400 lb
- GVWR
- 7000 lb
E4FB714TA2
7 ' x 14 ' Tandem Axle 4 " Channel Flatbed
- Curb Wt
- 1490 lb
- GVWR
- 7000 lb
E4FB716TA2
7 ' x 16 ' Tandem Axle 4 " Channel Flatbed
- Curb Wt
- 1580 lb
- GVWR
- 7000 lb
E4FB718TA2
7 ' x 18 ' Tandem Axle 4 " Channel Flatbed
- Curb Wt
- 1670 lb
- GVWR
- 7000 lb
E4FB720TA2
7 ' x 20 ' Tandem Axle 4 " Channel Flatbed w / Stabilizer Jacks
- Curb Wt
- 1760 lb
- GVWR
- 7000 lb
Available Units
Standard Features
- 2 5/16 " Coupler with 2K Top Wind Tongue Jack
- 15 ” Wheels & Tires ( Radial )
- Sealed Beam LED Lights
- PPG Primer and Paint
- 2 " x 6 " # 2 or Better Fir Decking
- Tube Tongue ( longer than competition )
- Brakes on Both Axles
- 6 ″ Bump Rail
- 5 ' Heavy Duty Stored Ramps
- 4 D - Rings
- 84 " Between Fenders
Popular Options
- Tongue Box Steel or Aluminum Diamond Plate
- Pressure Treated Decking
- Spare Tire and / or Mount
- Removable Fenders
- Rear Stabilizer Jacks
- Beavertail
- Fender High Rectangle or Round Tube Rail
- Steel Decking Diamond Plate / Smooth / Sand Texture
Specifications
- GAWR
- 7000
- Coupler Height
- 17"
- Deck Height
- 21"
- Frame
- 4" Channel
- Axle
- (2) 3,500# Posi-Lube Axles with Brakes
- Cross Members
- 2" x 3" x 3/16" Angle
- Decking
- 2 x 6 #2 or Better Fir Decking
- Bump Rail
- 2" x 2" Rectangle Tube, 6" High
- Coupler
- 2 5/16 " A-Frame Coupler
- Electric Plug
- 7-Way RV Molded Water Tight Plug
- Fenders
- 84" Between Fenders 9" x 66" Fenders
- Finish
- Steel is cleaned (wiped down) to ensure quality protective finish
- Jack
- 2K Top Wind Tongue Jack
- Lights
- Sealed Beam LED Lights
- Paint
- PPG Primer and Paint
- Ramps
- 5' Heavy Duty Stored
- Safety Chain
- 30" x 5/16" 7.6K Capacity
- Suspension
- Multi-Leaf Spring
- Tires
- ST 205/75 R15 Load Range C
- Tongue
- 2" x 4" Rectangular Tube
- Wheels
- 15 x 5 5-4.5 Mod (Silver)
Available Colors
Primary Colors
Black ALK-FP901
Eagle Majestic Grey
Optional Colors (Additional Cost)
White ALK-FP951
Bright Yellow ALK-FP801
Cat Yellow ALK-FP827
Ford Blue ALK-FP101
Ice Gray ALK-FP301
John Deer Green ALK-FP401
Kubota Orange ALK-FP601
Case IH Red ALK-FP701
