10K Eagle Tandem Axle

Back to Category

Models/Sizes (Pricing Varies Accordingly):

Model Code: EUC510TA3

Size: 5’ x 10’ Tandem Axle Ultra Classic

Curb Weight: 1825

GVWR: 10000

Model Code: EUC610TA3

Size: 6’ x 10’ Tandem Axle Ultra Classic

Curb Weight: 1865

GVWR: 10000

Model Code: EUC612TA3

Size: 6’ x 12’ Tandem Axle Ultra Classic

Curb Weight: 1970

GVWR: 10000

Model Code: EUC614TA3

Size: 6’ x 14’ Tandem Axle Ultra Classic

Curb Weight: 2075

GVWR: 10000

Model Code: EUC710TA3

Size: 7’ x 10’ Tandem Axle Ultra Classic

Curb Weight: 1945

GVWR: 10000

Model Code: EUC712TA3

Size: 7’ x 12’ Tandem Axle Ultra Classic

Curb Weight: 2050

GVWR: 10000

Model Code: EUC714TA3

Size: 7’ x 14’ Tandem Axle Ultra Classic

Curb Weight: 2115

GVWR: 10000

Model Code: EUC716TA3

Size: 7’ x 16’ Tandem Axle Ultra Classic

Curb Weight: 2275

GVWR: 10000

Model Code: EUC718TA3

Size: 7’ x 18’ Tandem Axle Ultra Classic

Curb Weight: 2425

GVWR: 10000

Model Code: EUC720TA3

Size: 7’ x 20’ Tandem Axle Ultra Classic

Curb Weight: 2645

GVWR: 10000

In-Stock Units

Loading available inventory...

Standard Features:

2 5/16” Coupler with 7K Drop Leg Jack
15” Wheels & Tires (Radial)
Sealed Beam LED Lights
PPG Primer and Paint
Tube Tongue (longer than competition)
Front Fender Step with Light
24” Ribbed Metal Sides
2” x 6” #2 or Better Fir Decking
Round Tube Top Rail
4’ Ramp Tailgate
Brakes on Both Axles

Popular Options (Additional Cost):

Tongue Box Steel or Aluminum Diamond Plate
Pressure Treated Decking
Spare Tire and/or Mount
Heavy Duty Stored 5’ Ramps ILO 4’ Ramp Gate
Rear Solid Metal Swing Gate
Rear Barn Doors
Spring Assist Ramps
No Gap Stake Pocket Top

Specifications:

GAWR	10400
Deck Height	22"
Frame	5" Channel
Cross Members	3" Channel
Decking	2 x 6 #2 or Better Fir Decking
Sides	24" 16 Gauge Smooth Steel 30" to Top of Rail
Coupler	Adjustable 2 5/16" Coupler
Fenders	9" x 72" Heavy Duty Double Broke Diamond Plate
Suspension	Multi-Leaf Spring
Coupler Height	Adjustable
Ramps	4' Ramp Tailgate
Uprights	2" x1" Rectangle Tube
Lights	Sealed Beam LED Lights
Electric Plug	7-Way RV Molded Water Tight Plug
Wheels	15 x 6 6-5.5 Mod (Silver)
Paint	PPG Primer and Paint
Finish	Steel is cleaned (wiped down) to ensure quality protective finish
Tires	ST 225/75 R15 Load Range D
Safety Chain	36" x 5/16" 11.7K Capacity
Jack	7K Drop Leg Jack
Tongue	2" x 5" Rectangular Tube
Top Rail	2" Round

Available Colors:

Primary Colors:

Black ALK-FP901

Eagle Majestic Grey

Optional Colors (Additional Cost):

White ALK-FP951

Bright Yellow ALK-FP801

Cat Yellow ALK-FP827

Ford Blue ALK-FP101

Ice Gray ALK-FP301

John Deer Green ALK-FP401

Kubota Orange ALK-FP601

Case IH Red ALK-FP701
