Models & Sizes
EUCLP508SA
5’ x 8’ Single Axle Ultra with Landscape Package
- Curb Wt
- 1060 lb
- GVWR
- 2990 lb
EUCLP510SA
5’ x 10’ Single Axle Ultra with Landscape Package
- Curb Wt
- 1150 lb
- GVWR
- 2990 lb
EUCLP610SA
6’ x 10’ Single Axle Ultra with Landscape Package
- Curb Wt
- 1230 lb
- GVWR
- 2990 lb
EUCLP612SA
6’ x 12’ Single Axle Ultra with Landscape Package
- Curb Wt
- 1330 lb
- GVWR
- 2990 lb
EUCLP6610SA
6’6” x 10’ Single Axle Ultra with Landscape Package
- Curb Wt
- 1310 lb
- GVWR
- 2990 lb
EUCLP6612SA
6’6” x 12’ Single Axle Ultra with Landscape Package
- Curb Wt
- 1370 lb
- GVWR
- 2990 lb
EUCLP6614SA
6’6” x 14’ Single Axle Ultra with Landscape Package
- Curb Wt
- 1400 lb
- GVWR
- 2990 lb
EUCLP710SA
7’ x 10’ Single Axle Ultra with Landscape Package
- Curb Wt
- 1370 lb
- GVWR
- 2990 lb
EUCLP712SA
7’ x 12’ Single Axle Ultra with Landscape Package
- Curb Wt
- 1430 lb
- GVWR
- 2990 lb
EUCLP714SA
7’ x 14’ Single Axle Ultra with Landscape Package
- Curb Wt
- 1520 lb
- GVWR
- 2990 lb
Available Units
Standard Features
- 2’ x 2’ Front Opening Lockable Tool Box with 6” Tray
- 6 Shovel and Rake Holders (Side Mount)
- 2 Place Weed Eater Rack
- Ladder Rack
- 2” Coupler with 2K Top Wind Tongue Jack
- 15” Wheels & Tires (Radial)
- Sealed Beam LED Lights
- PPG Primer and Paint
- 4’ Expanded Metal Ramp
- 2” x 6” #2 or Better Fir Decking
- Tube Tongue (longer than competition)
- Full Length Expanded Metal Steps
- Tongue Chain Tray
- Ribbed Metal Sides
Popular Options
- Pressure Treated Decking
- Spare Tire and/or Mount
- 3 Place Weed Eater Rack
Specifications
- GAWR
- 3500
- Coupler Height
- 16"
- Deck Height
- 19"
- Frame
- 2" x 3" Angle
- Axle
- 3,500# Posi-Lube Axle (Idler)
- Cross Members
- 2" x 3" Angle
- Decking
- 2 x 6 #2 or Better Fir Decking
- Sides
- 24" 16 Gauge Smooth Steel 30" to Top of Rail
- Coupler
- 2" A-Frame Coupler
- Electric Plug
- Flat 4-Way Molded Water Tight Plug
- Fenders
- 9" x 32"
- Finish
- Steel is cleaned (wiped down) to ensure quality protective finish
- Jack
- 2K Top Wind Tongue Jack
- Lights
- Sealed Beam LED Lights
- Paint
- PPG Primer and Paint
- Ramps
- 4' - 2" Tube
- Safety Chain
- 30" x 1/4" 5.2K Capacity
- Suspension
- Multi-Leaf Spring
- Tires
- ST 205/75 R15 Load Range C
- Tongue
- 2" x 3" Tube
- Top Rail
- 2" x 1" Tube
- Uprights
- 2" x 1" Tube
- Wheels
- 15 x 5 5-4.5 Mod (Silver)
Available Colors
Primary Colors
Black ALK-FP901
Eagle Majestic Grey
Optional Colors (Additional Cost)
White ALK-FP951
Bright Yellow ALK-FP801
Cat Yellow ALK-FP827
Ford Blue ALK-FP101
Ice Gray ALK-FP301
John Deer Green ALK-FP401
Kubota Orange ALK-FP601
Case IH Red ALK-FP701
